O.E.M. TOP LINKS
TOP LINK ASSEMBLY (REPLACES ZETOR / UESUS)
CODE |
PIPE A (MM) |
THREAD B |
LH BALL ID/HT (D1/H1) |
RH BALL ID/HT (D2/H2) |
TYPE |
| KTL 42370451 | 350 | M24X3 | 25.4/51 | 25.4/51 | 1 |
| KTL 46650440 | 400 | M24X2 | 25.4/51 | 25.4/44 | 1 |
| KTLMF 20-111 | 430 | M24X2 | 25.4/51 | 19.0/44 | 1 |
| KTL 3027824M91 | 430 | M24X2 | 25.4/44 | 25.4/44 | 1 |
| KTL 86450999 | 470 | M30X3.5 | 25.4/51 | 25.4/51 | 2 |
| KTL CC20-265 | 470 | M36X3 | 25.4/51 (80) | 25.4/51 (80) | 2 |
| KTL 89450999 | 470 | M36x3 | 32/51 (96) | 25.4/51 (80) | 2 |
| KTL 89450999-3 | 470 | M36x3 | 32/51 (96) | 32/51 (96) | 2 |
TOP LINK ASSEMBLY WITH RAPID HOOK (REPLACES ZETOR / UESUS)
CODE |
CAT d1-d2 |
PIPE L1 (INCH) |
THREAD D |
| KTL 88450999H | 3-2 | 440 | M36X3 |
TOP LINK ASSEMBLY (REPLACES M.T.Z. & U.M.Z.)
CODE |
PIPE A (MM) |
THREAD B |
LH BALL ID/HT (D1/H1) |
LH BALL ID/HT (D2/H2) |
TYPE |
| KTL/A.61.03.000 (BELARUS) | 360 | M30-TPZ | 22.1/51 | 22.1/51 | 22X100-R.H.S. |
| KTL/F50-4605090 (UMZ) | 360 | M30-TPZ | 22.1/51 | 25.4/51 | 25X100-R.H.S. |
