BALL JOINT WITH SLOT
CODE d D A B C E-SLOT
WOE 84450240 28.4 45 76 85 95 28X45X95 L
WOE 84450250 28.4 45 76 85 95 28X45X95 R
WOE 87450080 37 45 94 90 95 28X45X95 L
WOE 87450090 37 45 94 90 95 28X45X95 R
WELD ON END WITH BASE
CODE D E A B C
WOE 0621 28.4 45 100 130 100
WOE 0624 37 45 100 130 100
WOE 0624-38 38 45 100 130 100
TOP LINK BALL END WITH CENETERING PIN
CODE d D A B C E F G H
WOE 731 19 51 75 55 35 12 6 4 4
WOE 732 22.1 51 75 55 35 12 6 4 4
WOE 736 25.4 51 75 55 35 12 6 4 4
WOE 738 30 51 75 55 35 12 6 4 4
