CASE INTERNATIONAL LEVELLING ARM KIT(KCILAC22)

ADJUSTABLE LEVELLING ARM
CODE L (MIN) L (MAX) L1 D d H1 h1 d1 h2
KALA1930 380 530 230 M24X3 18 24 72 19.0 44
KALA1931 380 530 230 M24X3 18 24 72 22.1 35
KALA1940 410 560 260 M24X3 18 24 72 19.0 44
KALA1941 410 560 260 M24X3 18 24 72 22.1 35
KALA1943 490 660 340 M24X3 16 24 72 22.1 35
KALA1945 520 690 380 M24X3 16 24 72 22.1 35
ADJUSTABLE LEVELLING ARM
CODE L (MIN) L (MAX) L1 D d H h H1 h1
KALA1900 380 490 200 M22X2.5 18 30 60 24 72
KALA1910 450 600 260 M24X3 18 40 70 24 72
KALA1920 500 650 290 M27X3 18 40 70 24 72
