DOUBLE MOUNTING PIN / IMPLEMENT PIN
CODE A B C D E F G H I
DMP 07030 28 62 25 22 52 92 12 M24X1.5 190
DMP 07027 28 58 25 22 48 90 12 M24X2 195
DMP 07026 28 58 28 22 48 90 12 M27X3 195
DMP 07029 28 60 25 22 51 98 12 3"UNF 203
DMP 07002 28.6 62 25.4 22 52 84 12 1"UNF 190.5
DMP 07001 28.6 62 28 22 51 89 12 9/8"UNC 197
TOP LINK PIN WITH LINCH PIN
CODE D B C A
TPWL19092 19 77 6 92
TPWL19120 19 108 8 120
TPWL25120 25 98 8 120
CODE A B E C D
TPOH191 19 96 12 22 140
TPOH192 19 126 12 22 170
TPOH193 19 163 12 22 207
TPOH194 19 210 12 22 254
TPOH254 25 100 12 22 144
TPOH255 25 120 12 22 164
TPOH256 25 164 12 22 210
TPOH257 25 250 12 22 294
