DOUBLE MOUNTING PIN (TYPE - A)
CODE A B C D E F G H I J
DIP2219 28 22 22 40 67 115 30 200 12 6.5
DIP2520 28 25 22 40 67 115 30 200 12 6.5
DOUBLE MOUNTING PIN (TYPE - B)
CODE A B C D E F G
DIP2510 25 19 62 96 22 212 12
DIP2511 25 19 70 66 18 170 6.5
DIP2509 25 19 80 70 20 210 12
DIP2812 28 22 75 75 20 200 12
DIP2813 28 22 80 70 20 210 12
DIP2814 28 22 80 90 20 230 12
DIP3216 32 25 81 115 26 250 12
DIP3618 36.5 28 80 150 28 290 12
DIP3617 36.5 28 81 150 26 277 12
WELD ON END MOUTING PIN (TYPE - C)
CODE A B C D E F G
DMP02 28 22 12 76.5 104.5 88 60
DMP03 28 22 12 85 105 85 62
DMP04 28 22 12 103 78 60 87.3
DMP07 34 28 12 61 80 62 43.8
