ADJUSTABLE LEVELLING ASSEMBLY (J. D.)
| CODE | PIPE (A) MM |
THREAD (B) |
LH - U SIZE (C) |
RH -U SIZE (D) |
U. HOLE DIA (e/E) |
USABLE (L) |
||
| K-RMTE01 | 290 | M30 X 3.5RH | 46 X 62 | 24X52 | 18.5/19.5 | 460 | TYPE 1 | |
| K-RMTE02 | 490 | M30 X 3.5RH | 46 X 62 | 24X52 | 18.5/19.5 | 640 | TYPE 1 | |
| K-RMTE03 | 255 | M30X3.5RH | 19.0 (TL END) | 24X52 | 18.5 | 395 | 19X88 / 18X51 TL.PINL.S/R.S |
TYPE 2 |
LEVELLING ASSEMBLY (REPLACES URSUS & MF)
| CODE | PIPE (A) MM |
THREAD (B) |
USABLE C |
D | E | F | G |
| KALA 46650110 (RH) | 244 | M24 X 2.0 | 470 | 25.5 | 19.5 | 26X99 | 19.5X75 |
ADJUSTABLE LEVELLING ARM
| CODE | PIPE (A) MM |
THREAD (B) |
USABLE C |
D | E | F | G |
| KALA 1663853M91 (RH) | 300 | 3/4" UNC | 545 | 16.5 | 16.5 | 20X85 | 16 |
