PARKING JACK
CODE A B C D T H STROKE LOAD
CAP.
KPJ40300 40 300 95 115 2 430 150 250
KPJ40400 40 400 95 115 2 530 175 250
KPJ40500 40 500 95 115 2 630 200 250
KPJ50300 50 300 150 135 3 450 150 500
KPJ50400 50 400 150 135 3 550 175 500
KPJ50500 50 500 150 135 3 650 200 500
KPJ60400 60 400 150 135 3 550 175 700
KPJ60500 60 500 150 135 3 650 200 700
KPJ70400 70 400 150 180 3 550 175 1000
KPJ70500 70 500 150 180 3 650 200 1000
KPJ80500 80 500 150 180 4 650 200 1500
KPJ80600 80 600 150 180 4 750 250 1500
PARKING JACK WITH GEAR
CODE A B C D T H STROKE LOAD
CAP.
KPJG70500 70 500 220 220 3 620 200 1000
KPJG70600 70 600 220 220 3 720 250 1000
KPJG80500 80 500 220 220 4 620 200 1500
KPJG80600 80 600 220 220 4 720 250 1500
TIE ROD END (REPLACES MTZ)
CODE A B C D E F
KTRE A35.32.000-01(MTZ) 58.00 32.00 146.00 22X1.5RH 18X1.5RH 115.00
KTRE A35.32.000(MTZ) 58.00 32.00 146.00 22X1.5RH 18X1.5RH 115.00
TIE ROD ASSEMBLY (REPLACES MTZ)
CODE A B C
KTRA (MTZ) 50.3003010A2 260 M22X1.5 M18X1.5
KTRA (MTZ) 50.3003010A4 330 M22X1.5 M18X1.5
