SAFETY LOCK HITCH PIN (STANDARD DUTY) wire p1A 0.091”
| CODE | A | B | C | D |
| KSLHP-1/4-1.750 SD | 1/4" | 2.250" | 1.750" | 1.500" |
| KSLHP-1/4-2.500 SD | 1/4" | 3.000" | 2.500" | 1.500" |
| KSLHP-5/16-2.250 SD | 5/16" | 2.750" | 2.250" | 1.500" |
| KSLHP-5/16-4.000 SD | 5/16" | 4.438" | 4.000" | 2.000" |
| KSLHP-3/8-2.250 SD | 3/8" | 2.750" | 2.250" | 1.500" |
| KSLHP-3/8-4.000 SD | 3/8" | 4.438" | 4.000" | 2.000" |
| KSLHP-1/2-3.500 SD | 1/2" | 3.938". | 3.500" | 2.500" |
| KSLHP-5/8-4.000SD | 5/8" | 4.875" | 4.250" | 3.000" |
| KSLHP 3/4-4.000 SD | 3/4" | 5.750" | 4.000" | 2.000" |
SAFETY LOCK HITCH PIN (HEAVY DUTY) wire DIA 0.177"
| CODE | A | B | C | D |
| KSLHP-1/2-3.500 HD | 1/2" | 4.125" | 3.500" | 2.750" |
| KSLHP-5/8-4.000 HD | 5/8" | 4.734" | 4.000" | 3.000" |
| KSLHP-3/4-4.000 HD | 3/4" | 4.797" | 4.000" | 3.000" |
| KSLHP-3/4-6.000 HD | 3/4" | 6.797" | 6.000" | 3.000" |
| KSLHP-7/8-6.000 HD | 7/8" | 6.813" | 6.000" | 3.000" |
| KSLHP-1-6.250 HD | 1" | 7.061" | 6.250" | 3.000" |
