STABILIZER CHAIN ASSEMBLY
WEATHER CAP
CODE MIN MAX
KWC 001 40 45
KWC 002 50 55
KWC 003 60 65
KWC 004 75 81
DROP CLOSURE
CODE A B C
DC 1370 13 70 12.7
ACCELATOR END
CODE THREAD
KE 01 M6X 1 R.H
KE 02 M8X 1.25 R.H
KE 03 M10X 1.5 R.H
KE 01L M6X 1L.H
KE 02L M8X 1.25L.H
KE 03L M10X 1.5L.H
DROP CLOSURE
CODE A B C
DC 3570 35 70 M12
WHEEL SPINNER
CODE
KWS - 01
DROP CLOSURE
EITH LONG SCREW
CODE A B C
DC 7670 76 70 1/2" UNF
