WELD ON END MOUNTING PIN (TYPE- C)
| CODE | A | B | C | D | E | F | G |
| DMP02 | 28 | 22 | 12 | 76.5 | 104.5 | 88 | 60 |
| DMP03 | 28 | 22 | 12 | 85 | 105 | 85 | 62 |
| DMP04 | 28 | 22 | 12 | 103 | 78 | 60 | 87.3 |
| DMP07 | 34 | 28 | 12 | 61 | 80 | 62 | 43.8 |
DOUBLE MOUNTING PIN ( TYPE-D)
| CODE | A | B | C | D | E | F | G |
| DIP1921 | 19 | 16 | 5 | 74 | 55 | 16.5 | 156 |
| DIP2222 | 22 | 16 | 5 | 80 | 68 | 12 | 166 |
| DIP258 | 25 | 19 | 5 | 80 | 53 | 18 | 160 |
| DIP2524 | 25 | 19 | 5 | 90 | 57 | 18 | 180 |
| DIP2530 | 25 | 19 | 5 | 69 | 64 | 12 | 181 |
| DIP2825 | 28 | 22 | 5 | 90 | 57 | 18 | 180 |
| DIP2826 | 28 | 22 | 6 | 90 | 50 | 16.5 | 175 |
| DIP3229 | 32 | 25 | 6.5 | 80 | 55 | 22 | 172 |
