HAIR PIN (DOUBLE)
CODE | A | B | C | D |
HPD2065 | 2 | 65 | 9 | 10~12 |
HPD3071 | 3 | 71 | 15 | 12~16 |
HPD4077 | 4 | 77 | 18 | 16~30 |
HPD4093 | 4 | 93 | 22, | 17~24 |
HPD5108 | 5 | 108 | 24 | 17~24 |
HPD5116 | 5 | 116 | 22 | 17~24 |
HPD6120 | 6 | 120 | 30 | 28~42 |
HPD6143 | 6 | 143 | 30 | 28~42 |
HPD7162 | 7 | 162 | 30 | 30~45 |
HPD8155 | 8 | 155 | 30 | 45~60 |
HPD8162 | 8 | 162 | 45 | 45~60 |
HAIR PIN DOUBLE (LONG LEG)
CODE | A | B | C | D |
HPD5200 | 5 | 200 | 22 | 25~32 |
HAIR PIN DIN 11024
CODE | A | B | C | D |
HPD22554 | 2.25 | 54 | 20 | 9~11 |
HPD28061 | 2.80 | 61 | 20 | 11~14 |
HPD36078 | 3.60 | 78 | 20 | 14~20 |
HPD45097 | 4.50 | 97 | 25 | 20~26 |
HPD560115 | 5.60 | 115 | 25 | 26~34 |
HPD630146 | 6.30 | 146 | 30 | 34~45 |
HPD700169 | 7.00 | 169 | 30 | 45~56 |
CLIP PIN
CODE | A | B | C |
KHRSP315 A | 3X1.5 | 38 | 17 |
KHRSP525 | 5X2.5 | 56 | 27 |
